Circuit Wizard

This is a great app! It lets you enter your specs and then lets you know what size wire to use safely. I have searched for other wire size tables on the net, but none are as good as this one in my opinion.

Very quick and easy way to select appropriate wire size based on voltage drop or wire ampacity. I really wish the app had an option for 150°C wire insulation, as what's pretty commonly used in motorsports and aircraft; there is a large jump from 125°C to 200°C. In general, just allowing for a custom value for more of the settings would be an improvement. Also, for the duration field, you can just type off the screen as there is no character limit.

I have not yet compared this to the abyc tables but so far it sounds right and the additional options for wire bundling etc is a great reminder to keep thermal considerations in mind. A great app and another example of Blue Seas commitment to building a safe reliable and enjoyable boating and yachting experience

With this i no longer have to dig through my E-11 standards wire size table. It make things quicker and better. I love it

Fantastic for boat installers and electricians alike. Must have!
